Voltage Rating50V
Current Rating200mA
MountingSurface Mount
Quick Jump:
Technical Specifications
TE Connectivity 1746237-9 technical specifications.
General
| Contact Location | Bottom |
| Contact Material | Copper Alloy, Copper |
| Contact Plating | Tin, Gold |
| Current Rating | 200mA |
| Gender | Receptacle |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -20°C |
| Mount | Surface Mount |
| Number of Contacts | 27 |
| Number of Positions | 27 |
| Number of Rows | 1 |
| Orientation | Right Angle |
| Package Quantity | 1 |
| Packaging | Tape and Reel |
| Pitch | 0.3mm |
| Radiation Hardening | No |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | Yes |
| Termination | SMD/SMT |
| Voltage Rating | 50V |
Compliance
| RoHS | Compliant |
Datasheet
TE Connectivity 1746237-9 Datasheet
Download the complete datasheet for TE Connectivity 1746237-9 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
