Six-position, single-row wire-to-wire connector housing with a 3.5mm pitch, designed for straight, cable-mount applications. Features female socket contacts and a PBT body material, suitable for signal circuit applications. Operating temperature range from -22°C to 221°C, with a UL94 HB flammability rating. This polarized, free-hanging connector is lead-free and RoHS compliant.
MountingFree Hanging, Cable
PolarityYes
Quick Jump:
Technical Specifications
TE Connectivity 174923-1 technical specifications.
General
Body Material
PBT
Circuit Application
Signal
Color
Natural
Connector System
Wire-to-Wire
Contact Type
Female Socket
Depth
21.6mm
ELV
Compliant
Flammability Rating
UL94 HB
Gender
Female
Height
0.626inch
Housing Color
White
Hybrid Connector
No
Lead Free
Lead Free
Length
21.6mm
Mating Tab Width
1.8mm
Max Operating Temperature
221°C
Min Operating Temperature
-22°C
Mount
Free Hanging, Cable
Number of Contacts
6
Number of Positions
6
Number of Rows
1
Orientation
Straight
Package Quantity
100
Packaging
Bag
Pitch
3.5mm
Polarized
Yes
Primary Type
CONNECTOR
Radiation Hardening
No
RoHS Compliant
Yes
Sealable
No (Without)
Series
Multi-Lock
Serviceable
Yes
Strain Relief
No (Without)
Termination
Crimp
Width
0.961inch
Compliance
RoHS
Compliant
Datasheet
TE Connectivity 174923-1 Datasheet
Download the complete datasheet for TE Connectivity 174923-1 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
