1775470-2

2 Pos 2mm Shrouded Header, Male Pin, 3A, 250V, SMD

2-position shrouded header for wire-to-board applications, featuring a 2mm pitch and surface mount termination. This male pin connector offers a 3A current rating and 250V voltage rating, with brass contacts plated in tin, matte, and nickel. Designed for vertical PCB mounting, it operates within a -25°C to 85°C temperature range and is packaged on tape and reel.

Voltage Rating250V

Current Rating3A

MountingSurface Mount

Quick Jump:

Technical Specifications

TE Connectivity 1775470-2 technical specifications.

General

Backwall/Post Interruptions	No (Without)
Color	Natural
Connector System	Wire-to-Board
Contact Current Rating	3A
Contact Gender	Male
Contact Material	Brass
Contact Mating Length	3.5mm
Contact Plating	Tin, Matte, Nickel
Contact Post Length	2mm
Contact Retention	No (Without)
Contact Shape	Square
Contact Style	Pin
Contact Type	Male Pin
Current Rating	3A
ELV	Compliant
Flammability Rating	UL94 V-0
Height	6.15mm
Housing Color	Natural
Lead Free	Lead Free
Lead Length	2mm
Length	0.291inch
Mating Alignment	Yes (With)
Mating Retention	No (Without)
Max Operating Temperature	85°C
Min Operating Temperature	-25°C
Mount	Surface Mount
Number of Contacts	2
Number of Positions	2
Number of Rows	1
Operating Supply Voltage	250V
Package Quantity	500
Packaging	Tape and Reel
PCB Mount Alignment	No (Without)
PCB Mount Retention	With
PCB Mounting Orientation	Vertical
Pitch	0.079inch
Plating	Tin
Plating Thickness	2um
Radiation Hardening	No
RoHS Compliant	Yes
Sealable	No (Without)
Series	HPI
Strain Relief	No (Without)
Termination	SMD/SMT
Voltage Rating	250V
Width	5.4mm
Wire/Cable Type	Discrete
