2-644488-4

4 Pos Male Header, 2.54mm Pitch, 5A, Right Angle, Through Hole, Tin

4-position, single-row, right-angle wire-to-board header with a 2.54mm pitch. Features copper alloy male pins with tin, matte plating and nickel underplate, rated for 5A and 250V. Through-hole mounting with a solder termination, this black housing component operates from -67°C to 221°C and is UL94 V-0 flammability rated.

Voltage Rating250V

Current Rating5A

MountingThrough Hole

Quick Jump:

Technical Specifications

TE Connectivity 2-644488-4 technical specifications.

General

Approvals	CSA
Backwall/Post Interruptions	No (Without)
Color	Black
Connector System	Wire-to-Board
Contact Current Rating	5A
Contact Gender	Male
Contact Material	Copper Alloy
Contact Mating Length	5.1mm
Contact Plating	Tin, Matte
Contact Post Length	3.3mm
Contact Retention	No (Without)
Contact Shape	Square
Contact Type	Male Pin
Current Rating	5A
Depth	10.41mm
Flammability Rating	UL94 V-0
Height	10.41mm
Housing Color	Black
Length	12.29mm
Mating Alignment	Yes (With)
Mating Retention	Yes (With)
Max Operating Temperature	221°C
Min Operating Temperature	-67°C
Max Voltage Rating (AC)	250V
Mount	Through Hole
Number of Contacts	4
Number of Positions	4
Number of Rows	1
Orientation	Right Angle
Package Quantity	500
Packaging	Bag
PCB Mount Alignment	No (Without)
PCB Mount Retention	Without
PCB Mounting Orientation	Right Angle
PCB Thickness	0.063inch
Pitch	2.54mm
Plating	NICKEL PLATED
Plating Thickness	6.3um
Radiation Hardening	No
Reach SVHC Compliant	No
RoHS Compliant	Yes
Sealable	No (Without)
Series	MTA-100
Strain Relief	No (Without)
Tail Length	3.3mm
Termination	Solder
Underplate Material	Nickel
Voltage Rating	250V
