TE Connectivity

2008839-1

Name: 2008839-1 TE Connectivity
Brand: TE Connectivity
SKU: 2008839-1

1 Pos RA Header, 5A, 250V, 20AWG, LCP, Tin, Thru-Hole

1-position, right-angle receptacle for wire-to-board connectivity. Features a 4A contact current rating and 5A overall current rating, with a 250V AC voltage rating. Constructed from liquid crystal polymer with copper alloy contacts plated in matte tin. Designed for through-hole mounting on PCBs up to 0.062 inches thick, accepting 18-20 AWG discrete wire. Operates within a -40°C to 221°C temperature range and is UL94 V-0 flammability rated. Packaged in tape and reel for automated assembly.

Voltage Rating250V

Current Rating5A

MountingThrough Hole

Quick Jump:

Technical Specifications

TE Connectivity 2008839-1 technical specifications.

General

Approvals	CSA
Color	White, Natural
Connector System	Wire-to-Board
Contact Current Rating	4A
Contact Material	Copper Alloy, Tin, Copper
Contact Plating	Matte, Tin
Current Rating	5A
Depth	10.5mm
ELV	Compliant
Flammability Rating	UL94 V-0
Gender	Receptacle
Height	3.9mm
Housing Color	White
Insulation Diameter	0.0826inch
Lead Free	Lead Free
Length	10.5mm
Material	Liquid Crystal Polymer
Mating Alignment	No (Without)
Mating Retention	No (Without)
Max Operating Temperature	221°C
Min Operating Temperature	-40°C
Max Voltage Rating (AC)	250V
Mount	Through Hole
Number of Contacts	1
Number of Positions	1
Number of Rows	1
Orientation	Right Angle
Package Quantity	500
Packaging	Tape and Reel
PCB Mount Alignment	No (Without)
PCB Mount Retention	Without
PCB Thickness	0.062inch
Preloaded	Yes
Radiation Hardening	No
Reach SVHC Compliant	No
RoHS Compliant	Yes
Sealable	No (Without)
Termination	Through Hole
Voltage Rating	250V
Voltage Rating (AC)	250V
Width	0.156inch
Wire Gauge (Max)	20AWG
Wire Gauge (Min)	18AWG
Wire/Cable Gauge	22AWG
Wire/Cable Type	Discrete
