Four-position, wire-to-wire circular receptacle connector featuring male crimp contacts. Constructed with a black thermoplastic body and housing, this straight, panel-mount connector offers a 250V AC voltage rating and a 600V operating supply voltage. It boasts a UL94 V-0 flammability rating and is RoHS compliant, operating within a temperature range of -55°C to 105°C. The connector includes mating alignment and retention features, with a shell size of 11.
Voltage Rating250V
MountingPanel
Quick Jump:
Technical Specifications
TE Connectivity 206153-1 technical specifications.
General
Body Material
Thermoplastic
Color
Black
Connector System
Wire-to-Wire
Contact Gender
Male
Contact Protection
Yes (With)
Contact Shape
Circular
Contact Type
CRIMP
Depth
23.75mm
Diameter
23.75mm
ELV
Compliant
Flammability Rating
UL94 V-0
Gender
Receptacle
Height
20.75mm
Housing Color
Black
Insulation Material
Thermoplastic
Lead Free
Lead Free
Length
34.29mm
Material
Plastic
Mating Alignment
Yes (With)
Mating Retention
Yes (With)
Max Operating Temperature
105°C
Min Operating Temperature
-55°C
Max Voltage Rating (AC)
250V
Mount
Panel
Number of Contacts
4
Number of Ports
1
Number of Positions
4
Number of Signal Positions
4
Operating Supply Voltage
600V
Orientation
Straight
Package Quantity
1
Packaging
Bulk
Plating
Thermoplastic
Radiation Hardening
No
Ratings
IP65
Reach SVHC Compliant
No
RoHS Compliant
Yes
Sealable
No (Without)
Series
CPC Series 1
Shell Material
Nylon
Shell Size
11
Shielding
Unshielded
Strain Relief
No (Without)
Termination
Crimp
VDE Tested
No
Voltage Rating
250V
Compliance
RoHS
Compliant
Datasheet
TE Connectivity 206153-1 Datasheet
Download the complete datasheet for TE Connectivity 206153-1 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
