3-1634225-2

37 Pos D-Sub Female Connector, Vertical, Through Hole, Gold/Tin

37-position, 2-row D-subminiature connector with female contacts featuring gold and tin plating over nickel. This vertical through-hole mount connector has a steel shell, black housing, and includes mating connector lock and retention features. Designed for a 1.57mm PCB thickness with a 2.77mm pitch, it boasts UL approvals and a UL94 V-0 flammability rating.

PackageMetal

MountingThrough Hole

Quick Jump:

Technical Specifications

TE Connectivity 3-1634225-2 technical specifications.

General

Approvals	UL
Package/Case	Metal
Color	Black
Contact Gender	Female
Contact Material	Bronze
Contact Plating	Gold, Tin
Contact Post Length	4.3mm
Flammability Rating	UL94 V-0
Gender	Female
Housing Color	Black
Mating Connector Lock	Yes (With)
Mating Retention	Yes (With)
Mount	Through Hole
Number of Positions	37
Number of Rows	2
Package Quantity	40
Packaging	Tray
PCB Mount Retention	With
PCB Mounting Orientation	Vertical
PCB Thickness	1.57mm
Pitch	2.77mm
Plating	Nickel
Preloaded	Yes
RoHS Compliant	Yes
Sealable	No (Without)
Series	HD-20
Shell Material	Steel
Shell Size	C
Termination	Through Hole
Weight	0.634931oz
