Female ring tongue terminal for 16-22AWG wire, featuring a copper body with nickel plating for enhanced conductivity and corrosion resistance. This non-insulated terminal offers a circular termination with a stud diameter of 0.265 inches (M6) and a tongue thickness of 0.84mm. Designed for high-temperature applications, it includes insulated wire support and measures 26.19mm in length with a 11.91mm depth. The component is RoHS compliant and supplied in loose piece packaging.
MountingFree Hanging
Quick Jump:
Technical Specifications
TE Connectivity 322367 technical specifications.
General
Body Material
Copper
Body Plating
Nickel
Color
Yellow
Contact Material
Copper
Contact Plating
Nickel
Depth
11.91mm
ELV
Compliant
Features
High Temperature
Gender
Female
Government Qualified
No
Heavy Duty
No
Insulated Wire Support
Yes
Insulation
Non-Insulated
Insulation Diameter
0.14inch
Lead Free
Not Applicable
Length
26.19mm
Material
Copper
Mount
Free Hanging
Number of Holes
1
Package Quantity
1000
Packaging
Loose Piece
Plating
Nickel
Radiation Hardening
No
RoHS Compliant
Yes
Series
Diamond Grip, Strato-Therm
Stud Diameter
0.265inch
Stud Size
M6
Termination
Circular
Thickness
0.031inch
Tongue Thickness
0.84mm
Wire Gauge (Max)
22AWG
Wire Gauge (Min)
16AWG
Wire/Cable Diameter
3.56mm
Compliance
RoHS
Compliant
Datasheet
TE Connectivity 322367 Datasheet
Download the complete datasheet for TE Connectivity 322367 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
