Female, insulated butt splice terminal designed for crimp termination. Features a copper body and contact with tin plating. Accommodates two wire entries with a wire gauge range of 16AWG to 22AWG. Vinyl insulation provides a red color coding. RoHS compliant and ELV compliant.
Quick Jump:
Technical Specifications
TE Connectivity 34203 technical specifications.
General
| Body Material | Copper |
| Body Plating | Tin |
| Color | Red |
| Contact Material | Copper |
| Contact Plating | Tin |
| ELV | Compliant |
| Gender | Female |
| Government Qualified | No |
| Insulation | Insulated |
| Insulation Material | Vinyl |
| Lead Free | Not Applicable |
| Length | 26.16mm |
| Material | Copper |
| Number of Wire Entries | 2 |
| Orientation | Straight |
| Package Quantity | 1000 |
| Packaging | Loose Piece |
| Plating | Tin |
| Radiation Hardening | No |
| RoHS Compliant | Yes |
| Sealable | No (Without) |
| Series | Plasti-Grip |
| Termination | Crimp |
| Wire Gauge (Max) | 22AWG |
| Wire Gauge (Min) | 16AWG |
Compliance
| RoHS | Compliant |
Datasheet
TE Connectivity 34203 Datasheet
Download the complete datasheet for TE Connectivity 34203 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
