Female, straight, insulated terminal for wire gauges 10-12 AWG. Features a copper body with tin plating and a nylon insulation in yellow. Rated for 300V AC, this component has a crimp termination and a stud diameter of 0.328 inches (M8). It is RoHS compliant and government qualified.
MountingFree Hanging
Quick Jump:
Technical Specifications
TE Connectivity 35111 technical specifications.
General
| Body Material | Copper |
| Body Plating | Tin |
| Color | Yellow |
| Contact Material | Copper |
| Contact Plating | Tin |
| Depth | 13.49mm |
| Gender | Female |
| Government Qualified | Yes |
| Heavy Duty | No |
| Insulated Wire Support | Yes |
| Insulation | Insulated |
| Insulation Color | Yellow |
| Insulation Diameter | 6.35mm |
| Insulation Material | Nylon |
| Lead Free | Lead Free |
| Length | 33.58mm |
| Material | Copper |
| Mount | Free Hanging |
| Number of Holes | 1 |
| Orientation | Straight |
| Package Quantity | 500 |
| Packaging | Loose Piece |
| Plating | Tin |
| Plating Thickness | 2.54um |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Sealable | No (Without) |
| Series | PIDG |
| Stud Diameter | 0.328inch |
| Stud Size | M8 |
| Termination | Crimp |
| Thickness | 1.02mm |
| Tongue Thickness | 1.02mm |
| Voltage Rating (AC) | 300V |
| Width | 13.5mm |
| Wire Gauge (Max) | 12AWG |
| Wire Gauge (Min) | 10AWG |
| Wire/Cable Diameter | 6.35mm |
Compliance
| RoHS | Compliant |
Datasheet
TE Connectivity 35111 Datasheet
Download the complete datasheet for TE Connectivity 35111 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
