20-position, 2-row male header for board-to-board applications. Features surface mount termination with a 0.1" mating contact row spacing. Constructed with black thermoplastic insulator, rated for 3.6A signal current and 500VAC dielectric withstanding voltage. Operates within a -65°C to 105°C temperature range and meets UL 94V-0 flammability standards. Tin plated contacts ensure reliable termination.
MountingSTRAIGHT
Quick Jump:
Technical Specifications
TE Connectivity 5-147377-2 technical specifications.
General
| Max Operating Temperature | 105 |
| Min Operating Temperature | -65 |
| Termination Type | SURFACE MOUNT |
| Insulator Material | THERMOPLASTIC |
| Total Number of Contacts | 20 |
| Contact Gender | MALE |
| Reliability | COMMERCIAL |
| Manufacturer Series | 147377 |
| Mounting Style | STRAIGHT |
| Rated Current (Signal) | 3.6 |
| Dielectric Withstanding Voltage | 500VAC |
| Insulator Color | BLACK |
| UL Flammability Code | 94V-0 |
| Number Of PCB Rows | 2 |
| Plating Thickness | 30u |
| Number Of Connectors | ONE |
| Contact Finish Termination | Tin (Sn) |
| Mating Contact Row Spacing | 0.1 |
Compliance
| RoHS | Yes |
| Lead Free | Yes |
| REACH | Compliant |
| Military Spec | True |
Datasheet
TE Connectivity 5-147377-2 Datasheet
Download the complete datasheet for TE Connectivity 5-147377-2 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
