TE CONNECTIVITY

5917631-1

Datasheet

40 Pos 2 Row 0.05" Pitch Modular Ethernet Plug, Straight, Through Hole, Gold/Tin

TE Connectivity

5917631-1

Name: 5917631-1 TE Connectivity
Brand: TE Connectivity
SKU: 5917631-1

40 Pos 2 Row 0.05" Pitch Modular Ethernet Plug, Straight, Through Hole, Gold/Tin

40-position, 2-row male modular connector with a 0.05-inch pitch. Features gold and tin plated copper alloy contacts, a 3.1mm contact post length, and 0.12183-inch tail length for through-hole termination. This straight, vertical PCB mount connector has a 7mm height and a black housing, rated UL94 V-0 for flammability. It is RoHS and ELV compliant.

MountingThrough Hole

Quick Jump:

Technical Specifications

TE Connectivity 5917631-1 technical specifications.

General

Boss	No (Without)
Color	Black
Contact Material	Copper Alloy
Contact Plating	Gold, Tin
Contact Post Length	3.1mm
ELV	Compliant
Flammability Rating	UL94 V-0
Gender	Male
Height	7mm
Housing Color	Black
Mount	Through Hole
Number of Contacts	40
Number of Positions	40
Number of Rows	2
Orientation	Straight
Package Quantity	130
Packaging	Box
PCB Mount Alignment	No (Without)
PCB Mount Retention	Without
PCB Mounting Orientation	Vertical
Pitch	0.05inch
Plating Thickness	0.3um
RoHS Compliant	Yes
Series	Champ 050
Stackable	No
Tail Length	0.12183inch
Termination	Through Hole
