770846-1

4 Pos Power Connector, 5.08mm Pitch, 13A, RA Solder, Thru-Hole

4-position, right-angle wire-to-board power connector with a 5.08mm pitch. Features male pin contacts with bronze material and tin plating, rated for 12A contact current and 13A overall current. Housing is black, UL94 V-2 flammability rated, and the connector system supports through-hole mounting with mating and PCB mount retention. Operating temperature range is -67°C to 221°C with a 250V voltage rating.

Voltage Rating250V

Current Rating13A

MountingThrough Hole

Quick Jump:

Technical Specifications

TE Connectivity 770846-1 technical specifications.

General

Approvals	CSA
Circuit Application	Power
Color	Black
Connector System	Wire-to-Board
Contact Current Rating	12A
Contact Gender	Male
Contact Material	Bronze
Contact Plating	Tin
Contact Retention	No (Without)
Contact Type	Male Pin
Current Rating	13A
Flammability Rating	UL94 V-2
Height	12.29mm
Housing Color	Black
Length	23.27mm
Mating Alignment	Yes (With)
Mating Retention	Yes (With)
Max Operating Temperature	221°C
Min Operating Temperature	-67°C
Max Voltage Rating (AC)	250V
Mount	Through Hole
Number of Contacts	4
Number of Positions	4
Number of Power Positions	4
Number of Rows	1
Orientation	Right Angle
Package Quantity	200
Packaging	Box
PCB Mount Alignment	Yes (With)
PCB Mount Retention	With
PCB Mounting Orientation	Right Angle
Pitch	5.08mm
Radiation Hardening	No
RoHS Compliant	Yes
Sealable	No (Without)
Series	Commercial MATE-N-LOK
Strain Relief	No (Without)
Termination	Solder
VDE Tested	No
Voltage Rating	250V
Width	8.76mm
