2-position, right-angle plug for general interconnect applications. Features tin-plated bronze contacts, a green nylon housing, and a 5mm pitch. Rated for 15A and 300V AC, with a maximum operating temperature of 110°C. Supports free-hanging, panel, and PCB mounting with screw termination. Compliant with RoHS and ELV directives, and UL94 V-0 flammability rated.
Voltage300V
Current15A
Voltage Rating300V
Current Rating15A
Quick Jump:
Technical Specifications
TE Connectivity 796858-2 technical specifications.
General
Color
Green
Contact Material
Bronze
Contact Plating
Tin
Current
15A
Current Rating
15A
Depth
15.5mm
ELV
Compliant
Flammability Rating
UL94 V-0
Gender
Male
Housing Color
Green
Interlock
No (Without)
Length
19.8mm
Material
Nylon
Max Current Rating
15A
Max Operating Temperature
110°C
Min Operating Temperature
-40°C
Max Voltage Rating (AC)
300V
Mount
Free Hanging, Panel, PCB
Number of Circuits
2
Number of Contacts
2
Number of Levels
1
Number of Positions
2
Number of Positions Per Level
2
Number of Rows
1
Orientation
Right Angle
Package Quantity
300
Packaging
Carton
Pitch
5mm
Radiation Hardening
No
RoHS Compliant
Yes
Screw Flange
Yes (With)
Screwless Terminal Block
No (Without)
Series
Buchanan
Shrouded
Yes (With)
Side Stackable
No (Without)
Termination
Screw
Voltage
300V
Voltage Rating
300V
Width
18.4mm
Wire Gauge (Max)
30AWG
Wire Gauge (Min)
30AWG
Compliance
RoHS
Compliant
Datasheet
TE Connectivity 796858-2 Datasheet
Download the complete datasheet for TE Connectivity 796858-2 to view detailed technical specifications.
