General purpose terminal block with 2 positions and 5.08mm pitch. Features straight, male, screw termination with a 15A current rating and 300V voltage rating. Constructed with green polyamide housing and bronze contacts with tin plating. Offers panel mount capability and operates within a -40°C to 105°C temperature range. Compliant with RoHS and ELV standards, with UL94 V-0 flammability rating.
Voltage300V
Current15A
Voltage Rating300V
Current Rating15A
Quick Jump:
Technical Specifications
TE Connectivity 796861-2 technical specifications.
General
Color
Green
Contact Material
Bronze
Contact Plating
Tin
Current
15A
Current Rating
15A
Depth
12.5mm
ELV
Compliant
Flammability Rating
UL94 V-0
Gender
Male
Housing Color
Green
Interlock
Yes (With)
Lead Free
Lead Free
Length
20.32mm
Material
Polyamide
Max Current Rating
15A
Max Operating Temperature
105°C
Min Operating Temperature
-40°C
Max Supply Voltage (AC)
300V
Max Voltage Rating (AC)
300V
Mount
Free Hanging, Panel
Number of Circuits
2
Number of Contacts
2
Number of Levels
1
Number of Positions
2
Number of Positions Per Level
2
Number of Rows
1
Orientation
Straight
Package Quantity
300
Packaging
Carton
Pitch
5.08mm
Radiation Hardening
No
RoHS Compliant
Yes
Screw Flange
Yes (With)
Screwless Terminal Block
No (Without)
Series
Buchanan
Side Stackable
No (Without)
Termination
Screw
Voltage
300V
Voltage Rating
300V
Voltage Rating (AC)
300V
Width
12.5mm
Wire Gauge (Max)
30AWG
Wire Gauge (Min)
12AWG
Compliance
RoHS
Compliant
