Technical Specifications
Traco Power TCL240-124 technical specifications.
General
Current - Output 1
10A
Depth
110mm
Efficiency
88%
Flammability Rating
UL94 V-0
Isolation Voltage
1.5kV
Length
125mm
Max Input Voltage (AC)
264V
Min Input Voltage (AC)
85V
Max Input Voltage
132V
Min Input Voltage
85V
Max Operating Temperature
70°C
Min Operating Temperature
-10°C
Max Output Current
10A
Max Output Power
240W
Max Output Voltage
28V
Min Output Voltage
24V
Nominal Output Voltage
24V
Number of Outputs
1
Output Current
10A
Reach SVHC Compliant
No
Voltage - Output 1
24V
Weight
950g
Width
85mm
Compliance
RoHS
Compliant
Datasheet
Traco Power TCL240-124 Datasheet
Download the complete datasheet for Traco Power TCL240-124 to view detailed technical specifications.
