Technical Specifications
Traco Power TOF30-05S technical specifications.
General
Current - Output 1
6A
Depth
25mm
Efficiency
78%
Length
133mm
Max Input Voltage (AC)
264V
Min Input Voltage (AC)
85V
Max Input Voltage
264V
Min Input Voltage
85V
Max Operating Temperature
60°C
Min Operating Temperature
-10°C
Max Output Current
6A
Max Output Power
30W
Nominal Output Voltage
5V
Number of Outputs
1
Output Current
6A
Output Voltage
5V
Reach SVHC Compliant
No
Voltage - Output 1
5V
Weight
170g
Width
55mm
Compliance
RoHS
Compliant
Datasheet
Traco Power TOF30-05S Datasheet
Download the complete datasheet for Traco Power TOF30-05S to view detailed technical specifications.
