Traco Power
TSPC480-124
TRACOPOWER TSPC 480-124 AC/DC DIN Rail Power Supply, Industrial, Adjustable, Fixed, 1 Output, 85 VAC, 264 VAC, 480 W
MountingDIN Rail
Quick Jump:
Technical Specifications
Traco Power TSPC480-124 technical specifications.
General
Current - Output 1
20A
Depth
110mm
Efficiency
92%
Length
150mm
Max Input Voltage (AC)
264V
Min Input Voltage (AC)
85V
Max Input Voltage
132V
Min Input Voltage
85V
Max Operating Temperature
70°C
Min Operating Temperature
-25°C
Max Output Current
20A
Max Output Power
480W
Max Output Voltage
28V
Min Output Voltage
24V
Mount
DIN Rail
Nominal Output Voltage
24V
Number of Outputs
1
Output Current
20A
Reach SVHC Compliant
No
RoHS Compliant
Yes
Voltage - Output 1
24V
Weight
1950g
Width
115mm
Compliance
RoHS
Compliant
Datasheet
Traco Power TSPC480-124 Datasheet
Download the complete datasheet for Traco Power TSPC480-124 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
