Technical Specifications
TT OP250 technical specifications.
General
| Case Code (Imperial) | 1206 |
| Case Code (Metric) | 3216 |
| Package/Case | 1206 |
| Depth | 1.5mm |
| Forward Current | 50mA |
| Lead Free | Lead Free |
| Length | 3.2mm |
| Lens Style | Rectangular |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -25°C |
| Mount | Surface Mount |
| Number of Elements | 1 |
| Operating Supply Voltage | 30V |
| Orientation | Top View |
| Package Quantity | 1 |
| Packaging | Tape and Reel |
| Power Dissipation | 130mW |
| Reverse Voltage | 30V |
| RoHS Compliant | Yes |
| Viewing Angle | 160° |
| Wavelength | 880nm |
Compliance
| RoHS | Compliant |
Datasheet
TT OP250 Datasheet
Download the complete datasheet for TT OP250 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
