VAN DAMME

268542L

Datasheet

4-Conductor 24AWG 300V PVC Insulated Cable

VAN Damme

268542L

Name: 268542L VAN Damme
Brand: VAN Damme
SKU: 268542L

4-Conductor 24AWG 300V PVC Insulated Cable

This cable features 4 conductors made of copper, insulated with PVC, and has an outside diameter of 12mm. It is rated for 300V DC and AC, and has a 24AWG wire gauge. The cable is not SVHC compliant.

Voltage Rating300V

MountingCable

Quick Jump:

Technical Specifications

VAN Damme 268542L technical specifications.

General

Color	Black, Blue
Conductor Material	Copper
Jacket Material	PVC
Mount	Cable
Number of Conductors	4
Number of Cores	4
Outside Diameter	12mm
Reach SVHC Compliant	No
Voltage Rating	300V
Voltage Rating (AC)	300V
DC Rated Voltage	300V
Wire/Cable Gauge	24AWG
