Infrared (IR) LED emitter featuring a 950nm wavelength and GAAS technology. This through-hole component offers a 44° viewing angle and a radiant intensity of 190mW/sr. It operates with a forward current of 150mA and a maximum power dissipation of 210mW, with a reverse voltage rating of 5V. The emitter is housed in a T-1 3/4 package with a circular, diffused lens, designed for top mounting. It is RoHS compliant and lead-free, suitable for operation across a temperature range of -55°C to 85°C.
PackageRadial
MountingThrough Hole
Power210mW
Quick Jump:
Technical Specifications
Vishay TSUS5402 technical specifications.
General
Package/Case
Radial
Depth
5.8mm
Forward Current
150mA
Height
8.7mm
Lead Free
Lead Free
Length
5.8mm
Lens Style
Circular, Diffused
Max Operating Temperature
85°C
Min Operating Temperature
-55°C
Mount
Through Hole
Number of Elements
1
Number of LEDs
1
Orientation
Top View
Package Quantity
4000
Packaging
Bulk
Power Dissipation
210mW
Radiation Hardening
No
Reach SVHC Compliant
Unknown
Reverse Voltage
5V
Reverse Voltage (DC)
5V
RoHS Compliant
Yes
Technology
GAAS
Touchscreen
Infrared (IR)
Viewing Angle
44°
Wavelength
950nm
Width
5.8mm
Compliance
RoHS
Compliant
