12-position, 1-row male header for flexible flat cable (FFC) and flexible printed circuit (FPC) applications. Features a 5.08mm pitch and through-hole mounting with solder termination. Rated for 15A current and 300V voltage, with a maximum operating temperature of 100°C. Constructed with CuSn contacts plated in tin, housed in black UL94 V-0 flammability rated material. Approvals include CSA and UR, with RoHS compliance.
Voltage300V
Current18.5A
Voltage Rating300V
Current Rating15A
Quick Jump:
Technical Specifications
Weidmuller 1775102001 technical specifications.
General
Approvals
CSA, UR
Color
Black
Contact Material
CuSn
Contact Plating
Tin
Current
18.5A
Current Rating
15A
Flammability Rating
UL94 V-0
Gender
Male
Height
8.5mm
Housing Color
Black
Lead Free
Lead Free
Length
64.2mm
Max Operating Temperature
100°C
Min Operating Temperature
-50°C
Mount
Through Hole
Number of Contacts
12
Number of Levels
1
Number of Poles
12
Number of Positions
12
Number of Positions Per Level
12
Number of Rows
1
Packaging
Box
Pitch
5.08mm
Radiation Hardening
No
Reach SVHC Compliant
Unknown
RoHS Compliant
Yes
Series
Omnimate SL
Termination
Solder
Voltage
300V
Voltage Rating
300V
Width
12mm
Wire/Cable Gauge
12AWG
Compliance
RoHS
Compliant
Datasheet
Weidmuller 1775102001 Datasheet
