2-position, 2-row flexible flat cable (FFC) / flexible printed circuit (FPC) connector with ZIF/LIF termination. Features a 5.1mm terminal width and accepts wire gauges from 12 to 30 AWG. Rated for 300V and 24A, with a 6kV voltage rating. Constructed with beige thermoplastic insulation and a UL94 V-0 flammability rating. Cable mountable, this connector is RoHS compliant.
Voltage300V
Current20A
Voltage Rating6kV
Current Rating24A
Quick Jump:
Technical Specifications
Weidmuller 1855610000 technical specifications.
General
| Approvals | IEC, CSA, CE, UR |
| Color | Beige |
| Current | 20A |
| Current Rating | 24A |
| Flammability Rating | UL94 V-0 |
| Height | 48mm |
| Housing Color | Beige |
| Insulation Material | Thermoplastic |
| Length | 60mm |
| Max Current Rating | 24A |
| Mount | Cable |
| Number of Circuits | 1 |
| Number of Contacts | 2 |
| Number of Levels | 1 |
| Number of Positions | 2 |
| Number of Rows | 2 |
| Packaging | Bag |
| Radiation Hardening | No |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | Yes |
| Series | W |
| Terminal Width | 5.1mm |
| Termination | Screw |
| Voltage | 300V |
| Voltage Rating | 6kV |
| Width | 5.1mm |
| Wire Gauge (Max) | 30AWG |
| Wire Gauge (Min) | 12AWG |
Compliance
| RoHS | Compliant |
Datasheet
Weidmuller 1855610000 Datasheet
Download the complete datasheet for Weidmuller 1855610000 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
