Technical Specifications
Abracon AIML-1206-6R8K-T technical specifications.
General
| Case Code (Imperial) | 1206 |
| Case Code (Metric) | 3216 |
| Package/Case | 1206 |
| Core Material | Ferrite |
| DC Resistance (DCR) | 750mR |
| Height | 0.8mm |
| Inductance | 6.8uH |
| Length | 3.2mm |
| Max DC Current | 25mA |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Package Quantity | 3000 |
| Packaging | Tape and Reel |
| Q Factor | 40 |
| RoHS Compliant | Yes |
| Self Resonant Frequency | 34MHz |
| Series | AIML-1206 |
| Shielding | Shielded |
| Termination | SMD/SMT |
| Test Frequency | 4MHz |
| Tolerance | 10% |
| Width | 1.6mm |
Compliance
| RoHS | Compliant |
Datasheet
Abracon AIML-1206-6R8K-T Datasheet
Download the complete datasheet for Abracon AIML-1206-6R8K-T to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
