Technical Specifications
Alpha Wire F2601/8GY002 technical specifications.
General
Approvals
UL, CSA, NEC
Body Material
PO, Polyolefin
Color
Green, Yellow
Flammability Rating
UL224
Inside Diameter
0.125inch
Length
500foot
Material
Polyolefin, PO
Max Operating Temperature
135°C
Min Operating Temperature
-55°C
Package Quantity
1
Packaging
Spool
Reach SVHC Compliant
No
RoHS Compliant
Yes
Series
FIT®-260
Weight
6lb
Wire/Cable Diameter
3mm
Compliance
RoHS
Compliant
Datasheet
Alpha Wire F2601/8GY002 Datasheet
Download the complete datasheet for Alpha Wire F2601/8GY002 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
