Analog Devices
AD5399YRMZ
IC SERIAL INPUT LOADING, 0.8 us SETTLING TIME, 12-BIT DAC, PDSO10, 1.1 MM HEIGHT, MO-187BA, MSOP-10, Digital to Analog Converter
MountingSurface Mount
Power13mW
Quick Jump:
Technical Specifications
Analog Devices AD5399YRMZ technical specifications.
General
Contact Plating
Tin, Matte
Conversion Rate
1.25MS/s
Lead Free
Contains Lead
Max Operating Temperature
105°C
Min Operating Temperature
-40°C
Max Supply Voltage
5.5V
Min Supply Voltage
4.5V
Mount
Surface Mount
Nominal Supply Current
1.8mA
Number of Bits
12
Number of DAC Channels
2
Operating Supply Voltage
5V
Output Polarity
Unipolar
Output Type
Voltage
Power Dissipation
13mW
Resolution
12b
RoHS Compliant
Yes
Compliance
RoHS
Compliant
Datasheet
Analog Devices AD5399YRMZ Datasheet
Download the complete datasheet for Analog Devices AD5399YRMZ to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
