12-bit dual analog-to-digital converter (ADC) offering simultaneous sampling at 250 kSPS per channel. Features 1 LSB integral and differential nonlinearity, a 71 dB signal-to-noise ratio, and a parallel interface. Designed for through-hole mounting in a PDIP package, this component operates with single-ended inputs and a bipolar polarity, supporting a maximum input voltage of 2.625V. Power consumption is 60mW with a maximum supply voltage of 5V.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Analog Devices AD7862ANZ-10 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | PDIP |
| Differential Nonlinearity | 1LSB |
| Height | 4.95mm |
| Input Type | SINGLE-ENDED |
| Integral Nonlinearity (INL) | 1LSB |
| Interface | Parallel |
| Lead Free | Contains Lead |
| Length | 39.75mm |
| Max Input Voltage | 2.625V |
| Min Input Voltage | 2.375V |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Power Dissipation | 75mW |
| Max Supply Voltage | 5V |
| Mount | Through Hole |
| Nominal Supply Current | 15mA |
| Number of A/D Converters | 2 |
| Number of Analog Inputs | 4 |
| Number of Bits | 12 |
| Number of Channels | 4 |
| Number of Converters | 2 |
| Number of Inputs | 4 |
| Package Quantity | 13 |
| Packaging | Rail/Tube |
| Polarity | Bipolar |
| Power Consumption | 60mW |
| Power Dissipation | 75mW |
| Reach SVHC Compliant | No |
| Resolution | 12b |
| RoHS Compliant | Yes |
| Sampling Rate | 250KS/s |
| Signal to Noise Ratio (SNR) | 71dB |
| Width | 14.73mm |
| RoHS | Compliant |
