10-Bit, 8-Channel Analog-to-Digital Converter (ADC) with a 1 MSPS sampling rate. Features SPI interface, unipolar input, and single-ended input type. Offers 0.5 LSB differential and integral nonlinearity, with a full-scale error of 0.5 LSB. Operates from a 2.7V to 5.25V supply, consuming 600µA nominal current. Packaged in a 20-lead TSSOP with tin-matte contact plating.
PackageTSSOP
PolarityUnipolar
Power13.5mW
Quick Jump:
Technical Specifications
Analog Devices AD7918BRUZ technical specifications.
General
Package/Case
TSSOP
Contact Plating
Tin, Matte
Differential Nonlinearity
0.5LSB
Full Scale Error
0.5LSB
Height
1.05mm
Input Capacitance
20pF
Input Type
SINGLE-ENDED
Integral Nonlinearity (INL)
0.5LSB
Interface
SPI
Lead Free
Contains Lead
Length
6.5mm
Max Input Voltage
2.525V
Min Input Voltage
2.475V
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Max Power Dissipation
13.5mW
Max Supply Voltage
5.25V
Min Supply Voltage
2.7V
Nominal Supply Current
600uA
Number of A/D Converters
1
Number of Analog Inputs
8
Number of Bits
10
Number of Channels
8
Number of Converters
1
Number of Elements
1
Number of Inputs
8
Operating Supply Voltage
5V
Package Quantity
75
Packaging
Rail/Tube
Polarity
Unipolar
Power Dissipation
13.5mW
Radiation Hardening
No
Resolution
10b
RoHS Compliant
Yes
Sampling Rate
1MS/s
Signal to Noise Ratio (SNR)
61dB
Supply Type
Single
Width
4.4mm
Compliance
RoHS
Compliant
Datasheet
Analog Devices AD7918BRUZ Datasheet
Download the complete datasheet for Analog Devices AD7918BRUZ to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
