Single operational amplifier featuring a 10MHz gain bandwidth product and 4V/µs slew rate. Achieves 120dB common mode rejection ratio and 130dB power supply rejection ratio. Offers low input bias current of 3nA and input voltage noise density of 2.8nV/sqrt Hz. Operates from ±5V to ±15V dual supplies or 10V to 36V single supplies, with a maximum output current of 20mA per channel. Housed in an R package, this RoHS compliant component is supplied on tape and reel.
PackageR
Quick Jump:
Technical Specifications
Analog Devices AD8671ARZ-REEL7 technical specifications.
General
Amplifier Type
GENERAL PURPOSE
Package/Case
R
Common Mode Rejection Ratio
120dB
Contact Plating
Tin, Matte
Gain Bandwidth Product
10MHz
Input Bias Current
3nA
Input Capacitance
6.25pF
Input Offset Voltage (Vos)
75uV
Input Voltage Noise Density
2.8nV/sqrt Hz
Lead Free
Contains Lead
Max Dual Supply Voltage
15V
Min Dual Supply Voltage
5V
Max Operating Temperature
125°C
Min Operating Temperature
-40°C
Max Supply Voltage
36V
Min Supply Voltage
10V
Number of Amplifiers
1
Number of Channels
1
Number of Circuits
1
Number of Elements
1
Operating Supply Current
3.5mA
Output Current per Channel
20mA
Package Quantity
1000
Packaging
Tape and Reel
Power Supply Rejection Ratio (PSRR)
130dB
Quiescent Current
3.5mA
RoHS Compliant
Yes
Settling Time
5.1us
Slew Rate
4V/µs
Unity Gain Bandwidth Product
10MHz
Voltage Gain
135.56dB
Compliance
RoHS
Compliant
Datasheet
Analog Devices AD8671ARZ-REEL7 Datasheet
Download the complete datasheet for Analog Devices AD8671ARZ-REEL7 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
