10-bit, 125MS/s Digital-to-Analog Converter (DAC) with a 35ns settling time. Features a parallel interface and a single DAC channel. Offers a differential output and operates from a 4.5V to 5.5V supply voltage. Packaged in a TSSOP with tin, matte contact plating. Maximum power dissipation is 230mW.
PackageTSSOP
Power230mW
Quick Jump:
Technical Specifications
Analog Devices AD9750ARUZ technical specifications.
General
| Package/Case | TSSOP |
| Contact Plating | Tin, Matte |
| Conversion Rate | 125MS/s |
| Differential Output | Yes |
| Height | 1.05mm |
| Integral Nonlinearity (INL) | 1LSB |
| Interface | Parallel |
| Lead Free | Contains Lead |
| Length | 9.7mm |
| Max Input Voltage | 1.25V |
| Min Input Voltage | 100mV |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Output Voltage | 2.5V |
| Min Output Voltage | 100mV |
| Max Power Dissipation | 230mW |
| Max Supply Voltage | 5.5V |
| Min Supply Voltage | 4.5V |
| Number of Bits | 10 |
| Number of Converters | 1 |
| Number of D/A Converters | 1 |
| Number of DAC Channels | 1 |
| Operating Supply Voltage | 5V |
| Package Quantity | 50 |
| Packaging | Rail/Tube |
| Power Dissipation | 230mW |
| Reach SVHC Compliant | No |
| Resolution | 10b |
| RoHS Compliant | Yes |
| Sampling Rate | 125MS/s |
| Series | TxDAC® |
| Settling Time | 35ns |
| Width | 4.4mm |
Compliance
| RoHS | Compliant |
Datasheet
Analog Devices AD9750ARUZ Datasheet
Download the complete datasheet for Analog Devices AD9750ARUZ to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
