Technical Specifications
Analog Devices ADG738BRU technical specifications.
General
| -3db Bandwidth | 65MHz |
| Bandwidth | 65MHz |
| Package/Case | TSSOP |
| Height | 1.05mm |
| Interface | Serial |
| Lead Free | Contains Lead |
| Length | 5mm |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Power Dissipation | 100uW |
| Max Supply Voltage | 5.5V |
| Min Supply Voltage | 2.7V |
| Number of Channels | 8 |
| Number of Circuits | 1 |
| Number of Inputs | 8 |
| Number of Outputs | 1 |
| Operating Supply Voltage | 5V |
| Package Quantity | 96 |
| Packaging | Rail/Tube |
| RoHS Compliant | No |
| Throw Configuration | DPST |
| Width | 4.4mm |
Compliance
| RoHS | Not Compliant |
Datasheet
Analog Devices ADG738BRU Datasheet
Download the complete datasheet for Analog Devices ADG738BRU to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
