Analog Devices
ADG820BRMZ
Single SPDT Surface Mount Multiplexer, 1-Channel, 1-Input, 2-Outputs, 1.8V to 5.5V, -40°C to 125°C
The ADG820BRMZ is a single SPDT surface mount multiplexer from Analog Devices. It operates over a supply voltage range of 1.8V to 5.5V and has a maximum operating temperature of 125°C. The device is RoHS compliant and features a lead-free package. It is designed for use in logic IC applications and is available in a MICRO, SOIC-8 package type.
PackageMSOP
MountingSurface Mount
Quick Jump:
Technical Specifications
Analog Devices ADG820BRMZ technical specifications.
General
| Package/Case | MSOP |
| Lead Free | Lead Free |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -40°C |
| Max Supply Voltage | 5.5V |
| Min Supply Voltage | 1.8V |
| Mount | Surface Mount |
| Number of Bits | 1 |
| Number of Channels | 1 |
| Number of Inputs | 1 |
| Number of Outputs | 2 |
| RoHS Compliant | Yes |
| Throw Configuration | SPDT |
Compliance
| RoHS | Compliant |
Datasheet
Analog Devices ADG820BRMZ Datasheet
Download the complete datasheet for Analog Devices ADG820BRMZ to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
