Full duplex RS-232 transceiver with 5 drivers and 3 receivers, operating at 230Kbps. Features ±15kV ESD protection and EMI/EMC compliance. Through-hole mounted in a PDIP package with tin-matte plating. Operates from a 4.5V to 5.5V supply voltage with a maximum supply current of 13mA. Wide operating temperature range from -40°C to 85°C.
PackagePDIP
Current13mA
MountingThrough Hole
Quick Jump:
Technical Specifications
Analog Devices ADM207EANZ technical specifications.
General
Package/Case
PDIP
Contact Plating
Tin, Matte
Data Rate
230Kbps
ESD Protection
Yes
Height
3.3mm
Interface
RS-232
Lead Free
Contains Lead
Length
31.75mm
Logic Function
Transceiver, Receiver
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Max Supply Current
13mA
Max Supply Voltage
5.5V
Min Supply Voltage
4.5V
Mount
Through Hole
Number of Channels
3
Number of Drivers
5
Number of Receivers
3
Number of Transceivers
1
Number of Transmitters
5
Operating Supply Current
13mA
Operating Supply Voltage
5V
Package Quantity
15
Packaging
Rail/Tube
Radiation Hardening
No
Reach SVHC Compliant
No
Receiver Hysteresis
650mV
RoHS Compliant
Yes
Simplex/Duplex
Full Duplex
Supply Current
13mA
Width
6.35mm
Compliance
RoHS
Compliant
