5.0V precision voltage reference IC, featuring a fixed 5V output with 0.1% tolerance. This micropower device operates with a low 120uA supply current and supports a maximum output current of 5mA. Housed in a TSOT package, it offers a wide operating temperature range from -40°C to 125°C and a maximum input voltage of 18V. RoHS compliant and supplied in tape and reel packaging.
PackageTSOT
Quick Jump:
Technical Specifications
Analog Devices ADR395BUJZ-REEL7 technical specifications.
General
Package/Case
TSOT
Lead Free
Contains Lead
Max Input Voltage
18V
Max Operating Temperature
125°C
Min Operating Temperature
-40°C
Max Output Current
5mA
Max Output Voltage
5V
Min Output Voltage
5V
Operating Supply Current
120uA
Output Current
5mA
Output Type
Fixed
Output Voltage
5V
Packaging
Tape and Reel
Radiation Hardening
No
Reach SVHC Compliant
No
Reference Type
Series
Reference Voltage
5V
RoHS Compliant
Yes
Series
ADR39
Tolerance
0.1%
Compliance
RoHS
Compliant
Datasheet
Analog Devices ADR395BUJZ-REEL7 Datasheet
Download the complete datasheet for Analog Devices ADR395BUJZ-REEL7 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
