Technical Specifications
Analog Devices ADUM1310ARWZ-RL technical specifications.
General
Package/Case
SOIC
Channel Type
Unidirectional
Contact Plating
Tin, Matte
Data Rate
10Mbps
Isolated Power
No
Isolation Voltage
560V
Lead Free
Contains Lead
Max Operating Temperature
105°C
Min Operating Temperature
-40°C
Max Supply Voltage
5.5V
Min Supply Voltage
2.7V
Number of Channels
3
Package Quantity
1000
Packaging
Tape and Reel
Propagation Delay
100ns
Pulse Width Distortion (PWD)
40ns
RoHS Compliant
Yes
Series
iCoupler®
Supply Current
730uA
Type
General Purpose
Compliance
RoHS
Compliant
Datasheet
Analog Devices ADUM1310ARWZ-RL Datasheet
Download the complete datasheet for Analog Devices ADUM1310ARWZ-RL to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
