Boost DC/DC controller IC with a maximum output voltage of 72V and a maximum output current of 4A. Features a wide input voltage range from 6V to 40V and a maximum switching frequency of 533kHz. Operates with a high duty cycle of 94% and is designed for surface mount applications in a 28-pin TSSOP package. This component offers a single output and is RoHS compliant.
Frequency533kHz
PackageTSSOP
MountingSurface Mount
Quick Jump:
Technical Specifications
Analog Devices LT3782EFE#PBF technical specifications.
General
| Package/Case | TSSOP |
| Duty Cycle | 94% |
| Height | 0.7mm |
| Lead Free | Contains Lead |
| Length | 4mm |
| Max Frequency | 533kHz |
| Max Input Voltage | 6V |
| Min Input Voltage | 40V |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Output Current | 4A |
| Max Supply Voltage | 40V |
| Min Supply Voltage | 6V |
| Mount | Surface Mount |
| Number of Outputs | 1 |
| Output Current | 4A |
| Output Voltage | 72V |
| Package Quantity | 50 |
| Packaging | Rail/Tube |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Topology | Boost |
| Width | 5mm |
Compliance
| RoHS | Compliant |
Datasheet
Analog Devices LT3782EFE#PBF Datasheet
Download the complete datasheet for Analog Devices LT3782EFE#PBF to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
