Single-channel current sense operational amplifier featuring a 150kHz -3dB bandwidth and 150kHz gain bandwidth product. This IC offers a high Common Mode Rejection Ratio (CMRR) and Power Supply Rejection Ratio (PSRR) of 105dB, with a low input offset voltage of 300µV. Operating from a 2.7V to 36V supply, it draws a nominal 60µA operating supply current and delivers 15mA output current per channel. Packaged in an 8-MSOP configuration, this RoHS compliant component operates within a 0°C to 70°C temperature range.
PackageMSOP
Quick Jump:
Technical Specifications
Analog Devices LT6100CMS8#TRPBF technical specifications.
General
-3db Bandwidth
150kHz
Package/Case
MSOP
Common Mode Rejection Ratio
105dB
Input Offset Voltage (Vos)
300uV
Lead Free
Lead Free
Max Operating Temperature
70°C
Min Operating Temperature
0°C
Max Supply Voltage
36V
Min Supply Voltage
2.7V
Nominal Gain Bandwidth Product
150kHz
Number of Channels
1
Number of Circuits
1
Number of Elements
2
Operating Supply Current
60uA
Output Current per Channel
15mA
Package Quantity
2500
Packaging
Tape and Reel
Power Supply Rejection Ratio (PSRR)
105dB
Radiation Hardening
No
RoHS Compliant
Yes
Slew Rate
0.05V/µs
Compliance
RoHS
Compliant
Datasheet
Analog Devices LT6100CMS8#TRPBF Datasheet
Download the complete datasheet for Analog Devices LT6100CMS8#TRPBF to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
