Automotive OR Controller IC featuring a single N-channel MOSFET driver. Operates from a 2.9V to 6V supply voltage range with a maximum operating temperature of 70°C. Includes a 250ns turn-on delay and a 500ms turn-off delay. Packaged in a 12-pin MSOP, this RoHS compliant component is supplied in tubes of 37 units.
PackageMSOP
Quick Jump:
Technical Specifications
Analog Devices LTC4352CMS#PBF technical specifications.
General
Package/Case
MSOP
Max Operating Temperature
70°C
Min Operating Temperature
0°C
Max Supply Voltage
6V
Min Supply Voltage
2.9V
Number of Drivers
1
Number of Outputs
1
Package Quantity
37
Radiation Hardening
No
Reach SVHC Compliant
No
RoHS Compliant
Yes
Turn-Off Delay Time
500ms
Turn-On Delay Time
250ns
Compliance
RoHS
Compliant
Datasheet
Analog Devices LTC4352CMS#PBF Datasheet
Download the complete datasheet for Analog Devices LTC4352CMS#PBF to view detailed technical specifications.
