Surface mount shielded wirewound power inductor featuring 8.2µH inductance with a 20% tolerance. Designed with a carbonyl powder core, it offers a DC resistance of 68mΩ and a maximum DC current rating of 4A, with a saturation current of 7.5A. Operating across a wide temperature range of -40°C to 150°C, this component is AEC-Q200 qualified and RoHS compliant, suitable for automotive applications.
PackageNonstandard
MountingSurface Mount
Inductance8.2uH
Quick Jump:
Technical Specifications
Bourns SRP7028A-8R2M technical specifications.
General
Package/Case
Nonstandard
Core Material
Carbonyl Powder
DC Resistance (DCR)
68mR
Depth
6.6mm
Height
2.8mm
Inductance
8.2uH
Inductance Tolerance
20%
Length
7.3mm
Max DC Current
4A
Max Operating Temperature
150°C
Min Operating Temperature
-40°C
Mount
Surface Mount
Packaging
Cut Tape
Radiation Hardening
No
Ratings
AEC-Q200
Reach SVHC Compliant
No
RMS Current (Irms)
4A
RoHS Compliant
Yes
Saturation Current
7.5A
Self Resonant Frequency
17MHz
Series
SRP7028A
Shielding
Shielded
Termination
SMD/SMT
Test Frequency
100kHz
Tolerance
20%
Compliance
RoHS
Compliant
Datasheet
Bourns SRP7028A-8R2M Datasheet
Download the complete datasheet for Bourns SRP7028A-8R2M to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
