ASMT-AW00-NTUJ1

Single Color LED, Cool White, 6mm, ROHS COMPLIANT PACKAGE-2

PackageSMD/SMT

MountingSurface Mount, Board

Power1.4W

Quick Jump:

Broadcom ASMT-AW00-NTUJ1 technical specifications.

Package/Case	SMD/SMT
Color	White
Correlated Color Temperature (CCT)	10000K
Forward Current	350mA
Height	4.1mm
Illumination Color	White
Length	7.4mm
Lens Color	Clear
Luminous Flux	67.2lm
Max Current Rating	500mA
Max Operating Temperature	120°C
Min Operating Temperature	-40°C
Max Power Dissipation	1.75W
Mount	Surface Mount, Board
Package Quantity	250
Packaging	Tape and Reel
Power Dissipation	1.4W
Reach SVHC Compliant	No
RoHS Compliant	Yes
Series	ASMT-Ax00
Thermal Resistance of Package	10°C/W
Viewing Angle	140°
Width	7.4mm
