This 2-channel optical rotary switch features a vertical orientation and quadrature, incremental output type. It operates within a temperature range of 0-70°C and is available in a tray packaging with 50 units per package. The switch is suitable for through hole, panel, and PCB mounting.
MountingThrough Hole, Panel, PCB
Quick Jump:
Technical Specifications
Broadcom HRPG-AS16-17F technical specifications.
General
| Built in Switch | No |
| Detent | No |
| Encoder Type | Optical |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | 0°C |
| Mount | Through Hole, Panel, PCB |
| Number of Channels | 2 |
| Orientation | Vertical |
| Output Type | Quadrature, Incremental |
| Package Quantity | 50 |
| Packaging | Tray |
| Series | HRPG |
| Termination | PC Pin |
Compliance
| RoHS | Compliant |
Datasheet
Broadcom HRPG-AS16-17F Datasheet
Download the complete datasheet for Broadcom HRPG-AS16-17F to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
