PackageTO-220-2
Resistance47R
Voltage Rating250V
MountingThrough Hole
Quick Jump:
Technical Specifications
Caddock MP930-47.0-1% technical specifications.
General
Package/Case
TO-220-2
Features
Moisture Resistant
Height
0.65inch
Lead Diameter
0.76mm
Lead Length
12.7mm
Lead Pitch
5.08mm
Length
0.41inch
Max Operating Temperature
150°C
Min Operating Temperature
-55°C
Max Power Dissipation
30W
Mount
Through Hole
Number of Terminations
2
Package Quantity
50
Packaging
Rail/Tube
Resistance
47R
RoHS Compliant
Yes
Series
Kool-Pak®MP900
Termination
Radial
Tolerance
1%
Voltage Rating
250V
DC Rated Voltage
250V
Width
3.18mm
Compliance
RoHS
Compliant
Datasheet
Caddock MP930-47.0-1% Datasheet
Download the complete datasheet for Caddock MP930-47.0-1% to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
