Surface mount quartz crystal operating at 114.285MHz. Features 20ppm frequency tolerance and stability, with an 18pF load capacitance. This hermetically sealed, leadless ceramic package component offers an 80 Ohm ESR and operates within a -40°C to 85°C temperature range. RoHS compliant and available in cut tape packaging.
Frequency114.285MHz
PackageSMD/SMT
MountingSurface Mount
Quick Jump:
Technical Specifications
Connor-Winfield CS-023-114.285M technical specifications.
General
Package/Case
SMD/SMT
ESR (Equivalent Series Resistance)
80R
Frequency
114.285MHz
Frequency Stability
20ppm
Frequency Tolerance
20ppm
Load Capacitance
18pF
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Mount
Surface Mount
Packaging
Cut Tape
RoHS Compliant
Yes
Series
CS-023
Compliance
RoHS
Compliant
Datasheet
Connor-Winfield CS-023-114.285M Datasheet
Download the complete datasheet for Connor-Winfield CS-023-114.285M to view detailed technical specifications.
