PackageModule
MountingPanel, Chassis Mount, Chassis, Screw
Quick Jump:
Technical Specifications
Crydom UPD2415DF-10 technical specifications.
General
Package/Case
Module
Depth
28.45mm
Height
12.7mm
Input Type
DC
Length
78.23mm
Load Current
15A
Max Operating Temperature
80°C
Min Operating Temperature
-40°C
Mount
Panel, Chassis Mount, Chassis, Screw
Package Quantity
20
Packaging
Bulk
Reach SVHC Compliant
No
Relay Type
Relay
RoHS Compliant
Yes
Series
UPD24D
Termination
Quick Connect
Throw Configuration
DPST
Turn-On Delay Time
0.02ms
Compliance
RoHS
Compliant
Datasheet
Crydom UPD2415DF-10 Datasheet
Download the complete datasheet for Crydom UPD2415DF-10 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
