Frequency300MHz
PackageSOT-23
MountingSurface Mount
PolarityNPN
Quick Jump:
Technical Specifications
Diotec BC849B technical specifications.
General
Package/Case
SOT-23
Collector Base Voltage (VCBO)
30V
Collector Emitter Voltage (VCEO)
30V
Emitter Base Voltage (VEBO)
5V
Frequency
300MHz
Max Operating Temperature
150°C
Min Operating Temperature
-55°C
Mount
Surface Mount
Number of Elements
1
Packaging
Tape and Reel
Polarity
NPN
Power Dissipation
250mW
RoHS Compliant
Yes
Compliance
RoHS
Compliant
Datasheet
Diotec BC849B Datasheet
Download the complete datasheet for Diotec BC849B to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
