Current Rating8A
MountingPanel, Front
Quick Jump:
Technical Specifications
E-Switch D16EER14BGRN technical specifications.
General
Actuator Type
Round, Button
Contact Plating
Silver
Current Rating
8A
Electrical Life
50000Cycles
Illumination Color
Green
Illumination Type
Illuminated
Max Operating Temperature
55°C
Mechanical Life
100000Cycles
Min Operating Temperature
-20°C
Mount
Panel, Front
Packaging
Bulk
RoHS Compliant
No
Series
D16
Switch Function
On-On
Termination
Solder
Throw Configuration
4PDT
Voltage Rating (AC)
125V
DC Rated Voltage
24V
Compliance
RoHS
Not Compliant
Datasheet
E-Switch D16EER14BGRN Datasheet
Download the complete datasheet for E-Switch D16EER14BGRN to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
