Eaton
FAZ-C20/1
EATON MOELLER FAZ-C20/1 Thermal Magnetic Circuit Breaker, 415 VAC, 48 VDC, 20 A, 1 Pole, DIN Rail
Voltage Rating230V
Current Rating20A
Quick Jump:
Technical Specifications
Eaton FAZ-C20/1 technical specifications.
General
Current Rating
20A
Depth
73.5mm
Length
80mm
Number of Poles
1
Reach SVHC Compliant
No
RoHS Compliant
Yes
Series
FAZ
Voltage Rating
230V
Voltage Rating (AC)
415V
DC Rated Voltage
48V
Width
17.5mm
Compliance
RoHS
Compliant
Datasheet
Eaton FAZ-C20/1 Datasheet
Download the complete datasheet for Eaton FAZ-C20/1 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
