SPDT electromechanical relay featuring a 12VDC coil with 30mA current and 360mW power consumption. This general-purpose relay offers a 10A contact current rating with Tin, Silver contacts and a 250V AC/DC switching voltage. Designed for PCB mounting with through-hole termination, it operates within a -40°C to 85°C temperature range and boasts an IP67 rating.
Current Rating10A
MountingPCB
Quick Jump:
Technical Specifications
Finder 36.11.9.012.4011 technical specifications.
General
Application(s)
POWER
Coil Current
30mA
Coil Power
360mW
Coil Resistance
400R
Coil Type
Non-Latching
Coil Voltage (DC)
12V
Contact Current Rating
10A
Contact Material
Tin, Silver
Current Rating
10A
Depth
15.5mm
Height
15mm
Length
19mm
Life (Hours)
50Hour
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Mount
PCB
Number of Contacts
1
Ratings
IP67
Reach SVHC Compliant
No
RoHS Compliant
Yes
Switching Current
10A
Switching Voltage
250V
Termination
Through Hole
Test Voltage
2.5kV
Throw Configuration
SPDT
Voltage Rating (AC)
250V
Compliance
RoHS
Compliant
Datasheet
Finder 36.11.9.012.4011 Datasheet
Download the complete datasheet for Finder 36.11.9.012.4011 to view detailed technical specifications.
No datasheet is available for this part.
