Finder
36.11.9.024.4001
Electromechanical Relay 24VDC 1.6KOhm 15A SPDT(19x15.5x16)mm THT Miniature Relay
MountingPCB
Quick Jump:
Technical Specifications
Finder 36.11.9.024.4001 technical specifications.
General
Coil Current
15mA
Coil Power
360mW
Coil Resistance
1.6kR
Coil Voltage (DC)
24V
Contact Current Rating
10A
Contact Material
Tin, Silver
Contact Type
SPDT-CO
Depth
15.5mm
Height
17.5mm
Length
21.5mm
Life (Hours)
10000000Hour
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Mount
PCB
Ratings
IP67
Reach SVHC Compliant
No
Switching Current
10A
Switching Voltage
30V
Termination
Through Hole
Throw Configuration
SPDT
Width
15.5mm
Compliance
RoHS
Compliant
Datasheet
Finder 36.11.9.024.4001 Datasheet
Download the complete datasheet for Finder 36.11.9.024.4001 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
