Programmable multi-delay relay featuring a single-pole double-throw (SPDT) contact configuration. Offers adjustable time delays from 0.1 seconds to 86,400 seconds, with 6 selectable functions. Coil operates at 240VDC with a 0.004A current draw and 1000mW power consumption. Contacts are rated for 16A switching current and 400V switching voltage, with Silver/Cadmium contact material. Unit mounts to DIN rail and measures 84mm length, 60.8mm height, and 17.5mm width.
PackageModule
MountingDIN Rail
Quick Jump:
Technical Specifications
Finder 80.01.0.240.0000 technical specifications.
General
Package/Case
Module
Coil Voltage (AC)
240V
Coil Voltage (DC)
240V
Contact Material
Silver, Cadmium
Contact Type
SPDT-CO
Depth
60.8mm
Height
60.8mm
Length
84mm
Max Current Rating
16A
Max Operating Temperature
50°C
Min Operating Temperature
-10°C
Max Supply Voltage
240V
Mount
DIN Rail
Number of Contacts
1
Number of Functions
6
Ratings
IP20
Reach SVHC Compliant
No
RoHS Compliant
Yes
Switching Current
16A
Switching Voltage
400V
Termination
Screw
Voltage Rating (AC)
250V
Width
17.5mm
Compliance
RoHS
Compliant
Datasheet
Finder 80.01.0.240.0000 Datasheet
Download the complete datasheet for Finder 80.01.0.240.0000 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
